Advanced Engineering for Extreme Industrial Environments

The URSUS-FEICHUN cable series represents cutting-edge German engineering excellence in flexible power transmission solutions. Specifically engineered for applications demanding exceptional mechanical resilience, this professional-grade cable withstands extreme tensile forces and continuous torsional stress while maintaining optimal electrical performance in the harshest industrial conditions.

Mission-Critical Applications: Harbor crane operations, container handling systems, conveyor installations, and heavy-duty vertical reeling mechanisms across global industrial infrastructure.

Technical Engineering Specifications

Electrical Performance Parameters

ParameterSpecificationStandard Compliance
Nominal Rated Voltage U₀/U0.6/1 kVVDE 0250 Part 814
Test Voltage (AC)4 kVDIN VDE Standards
Maximum AC Operating Voltage0.7/1.2 kVVDE 0298 Part 4
Maximum DC Operating Voltage1.8 kVInternational Standards
Current RatingPer VDE 0298 Part 4German Engineering Standards

Mechanical Performance Characteristics

PropertyValueTesting Standard
Maximum Torsional Stress±50°/mVDE 0298 Part 3
Maximum Tensile Load30 N/mm² (conductor cross-section)Professional Reeling Test
Maximum Working Speed180 m/minDynamic Testing Protocol
Bending RadiusPer VDE 0298 Part 3German Standards

Environmental Resistance Properties

Environmental FactorPerformance RatingTest Method
Maximum Conductor Temperature90°C continuous operationThermal Analysis
Short Circuit Temperature250°C maximumEmergency Conditions
Minimum Ambient (Mobile)-30°CDynamic Applications
Minimum Ambient (Static)-50°CFixed Installation
Oil ResistanceExcellentIEC 60811-404
Ozone ResistanceSuperiorIEC 60811-403
UV ResistanceEnhancedISO 4892-2
Flame RetardancyCompliantIEC 60332-1-2

Advanced Material Engineering

Conductor Configuration

Premium tinned copper conductors manufactured to Class 5 flexibility standards according to VDE 0295 (IEC 60228). The tinning process provides enhanced corrosion resistance and superior electrical contact properties, critical for marine and industrial environments where moisture and chemical exposure are prevalent.

Insulation Technology

Specialized 3GI3 rubber compound insulation conforming to VDE 0207 Part 20 standards. This advanced formulation delivers exceptional dielectric properties while maintaining flexibility across extreme temperature ranges. Thickness specifications adhere strictly to VDE 0250 Part 814 requirements.

Anti-Twisting Innovation

Integrated polyester braid anti-twisting element positioned strategically between inner and outer sheath layers. This engineering solution prevents cable deformation during continuous reeling operations and maintains structural integrity under high torsional stress conditions.

Protective Sheathing System

Dual-layer protection featuring specialized 5GM5 quality rubber compounds per VDE 0207 Part 21. The distinctive yellow outer sheath provides immediate visual identification while delivering superior resistance to abrasion, crushing, and environmental degradation.

Product Configuration Matrix

Three-Core Configurations (3G Series)

Cross Section (mm²)Conductor Ø (mm)Overall Ø Min (mm)Overall Ø Max (mm)Weight (kg/km)Max Tensile Load (N)
3G1.51.513.814.8270135
3G2.51.915.316.3330225
3G42.417.018.0420360
3G62.918.319.3520540
3G103.821.423.3750900
3G164.823.525.49701440
3G256.928.230.214502250
3G357.831.633.618903150
3G509.336.838.826004500
3G7011.140.443.333406300
3G9512.746.349.243808550
3G12014.549.952.9533010800
3G15016.755.458.4670013500
3G18517.662.666.5810016650
3G24020.667.870.21085021600

Four-Core & Five-Core Configurations

ConfigurationCross Section (mm²)Overall Ø Max (mm)Weight (kg/km)Max Tensile Load (N)
4G1.51.515.6300180
4G252534.219003000
4G505042.932506000
4G18518571.41016022200
5G1.51.516.5350225
5G252537.022903750
5G505046.539407500
5G707053.0530010500

Global Standards Compliance & Regional Designations

European Union Standards

Germany: (N)SHTÖU – O/J designation per DIN VDE 0250 Part 814
France: Câble industriel flexible HO7RN-F équivalent
United Kingdom: Heavy duty flexible cable BS EN 50525-2-21
Netherlands: Zwaar industriële flexibele kabel

Asia-Pacific Region

China: 重型工业软电缆 (GB/T 12706 equivalent)
Japan: 重工業用フレキシブルケーブル (JIS C 3312 equivalent)
South Korea: 중공업용 가요성 케이블 (KS C IEC standards)
Australia: Heavy duty flexible cable AS/NZS 5000.1

North American Standards

United States: Heavy duty portable cord – Type W (UL 62 equivalent)
Canada: Extra hard usage flexible cord (CSA C22.2 equivalent)

International Marine & Port Standards

IMO Compliance: International Maritime Organization requirements
Lloyd’s Register: Marine cable classification standards
DNV GL: Offshore and marine certification protocols

Frequently Asked Questions & Technical Guidance

What distinguishes URSUS-FEICHUN cables from standard industrial power cables?
URSUS-FEICHUN cables incorporate specialized anti-twisting polyester braid technology and dual-layer 5GM5 rubber sheathing. This engineering approach delivers superior resistance to continuous flexing, torsional stress, and mechanical deformation compared to conventional industrial cables. The tinned copper conductors and 3GI3 insulation compound provide enhanced electrical performance in harsh environmental conditions.
How does the maximum working speed of 180 m/min benefit crane operations?
The 180 m/min specification enables rapid load positioning in high-throughput port operations and container handling facilities. This speed capability reduces cycle times while maintaining cable integrity, directly impacting operational efficiency in time-critical industrial applications such as ship-to-shore crane operations and automated container terminals.
What is the significance of the ±50°/m torsional stress rating?
The ±50°/m torsional stress specification indicates the cable’s ability to withstand rotational forces during reeling operations. This parameter is crucial for applications involving continuous winding and unwinding, such as cable drums on rotating cranes or mobile equipment. The anti-twisting element prevents conductor displacement and maintains electrical continuity under extreme rotational stress.
How do environmental resistance properties benefit marine applications?
The combination of oil resistance (IEC 60811-404), ozone resistance (IEC 60811-403), and UV resistance (ISO 4892-2) makes URSUS-FEICHUN cables ideal for marine environments. These properties prevent degradation from salt spray, hydraulic fluids, and intense sunlight exposure common in port facilities, shipyards, and offshore installations.
What installation considerations apply for extreme temperature environments?
For mobile applications down to -30°C, standard URSUS-FEICHUN cables maintain flexibility and electrical performance. For static installations requiring operation to -50°C, specific installation procedures ensure optimal performance. For environments below -40°C in mobile applications, the URSUS VS K variant provides enhanced cold weather performance.
How does the laying-up specification affect installation requirements?
The ≤8 times laying-up cores diameter specification defines minimum bend radius requirements during installation. This parameter ensures conductor integrity and prevents insulation damage during cable routing through drum systems, cable trays, and confined spaces in industrial installations.
